specially designed for industrial environments
-40°c-85°c industrial class wide temperature design
industrial class aluminum alloy shell, integrated casting technology
din rail installation, construction is simple and flexible
dual redundant power input, dual anti-static
6kv industrial class lightning protection，being used extensively
| product model | nis1005 pro |
| port | 5*10/100mbps rj45 ports |
| standards and protocols | ieee 802.3 ethernet media access control protocol ieee 802.3i 10base-t ethernet ieee 802.3u 100base-tx fast ethernet ieee 802.3x flow control |
| backplane bandwidth | 1g |
| mac address table | 2k |
| power supply | dc 12~36v |
| network medium |
100base-tx: 4*（cat5e）or above utp/stp(≤100m) 100base-tx: 2*（cat5）or above utp/stp(≤100m) |
| size | 110mm*87mm*36mm |
| working environment |
operating temperature: -40°c ~ 85°c storage temperature: -45°c ~ 85°c operating humidity: 10% ~ 90%, rh non-condensing storage humidity: 5% ~ 90%, rh non-condensing |
