offer you simultaneous dual band connection with 867mbps wireless speeds over 5ghz band and 300mbps over the 2.4ghz band. 1-4 variable wan ports, load balancing strategy brings better broadband overlay effect. wechat remote management. "push-to-reset" button quickly restores the correct internet configuration
product model |
nb1200gc |
standard protocol | ieee802.3,ieee802.3u,ieee802.3z ,ieee802.3x,ieee802.1x,ieee802.11 b/g/n/ac |
port |
lan:4*10//100/100/1000m auto mdi/mdix rj45 ports |
forwarding rate | 10/100/1000m |
flash | 16mb |
memory | 128mb |
power | dc 12v/1a |
size | 200×124.4×28mm |
operating environment | operating temperature: 0°c ~ 40°c
storage temperature: -20°c ~ 70°c operating humidity: 10% ~ 90%, non-condensing storage humidity: 5% ~ 90%, non-condensing |
led indicator | pwr、sys、2.4g、5g、wan1、lan1、lan2、lan3、lan4 |
common functions | multi-wan port access (support dynamic ip/pppoe/static ip dial-up mode, wan port automatically detects the access type) one key speed test store scene settings wechat to wi-fi one-click switch child mode, worry-free parent control one-click sos to restore user configuration smart qos dhcp service wisp universal relayport mapping peanut shell domain name access device monitoring pptp/l2tp client |
security |
malicious url blocking lan attack defense anti-wi-fi squatter intrusion blacklist management |
basic settings |
system upgrade restart router reset dial log developer mode |
other | wechat management emergency recovery |
description:
[new]
1, the new ac controller function, can control the ten lei family ap (nap874 / nap876 / nap872/ nap881 / nap850/ nap840 )
2. added the parameter synchronization process with repeater r1200
[repaired]
1. repair the source of one-key velocity measurement
2. rectify the vpn client dial-up failure after the domain name mapping address is changed
upgrade description:
1. add "host scene" in scene mode. after configuration, two independent wifi with dual frequency integration will be transmitted, and the priority of the host's dedicated wifi will be increased;
2. add the policy-based routing function.
3. add the intranet detection function.
