wifi 6 wireless protocol is supported
equipped with 1ghz high-end chip, 256mb flash memory 128m memory
all gigabit ports enjoy gigabit network speed, 1800mbps wireless dual-band signal
mu-mimo ofdma technology, lower delay, faster speed
model | nx1-t (wifi6) |
supported standards and protocols | ieee802.11 b/g/n/ac/ax |
port |
1个10/100/1000m auto mdi/mdix rj45 wan port |
forwarding rate | 10/100/1000mbps |
wireless specifications | 2.4g band: 574mbps; 5g band: 1201mbps |
antenna | 6 high-gain omnidirectional antennas |
cpu | 1ghz (dual core) |
ram | 256mb(internally packaged in the main ic) |
rom | 128mb |
button | default×1 |
led indicator | pwr、internet、wifi、lan1、lan2、lan3、wan |
size | 236mm×144mm×50mm |
power supply | 12v/1a |
operating environment | operating temperature: 0°c ~ 40°c storage temperature: -20°c ~ 70°c operating humidity: 10% ~ 90%, non-condensing storage humidity: 5% ~ 90%, non-condensing |
common functions |
quick configuration |
security |
malicious url firewall |
basic settings |
system upgrade |
others |
emergency recovery xiaoyi app |
