24ge poe 2ge sfp uplink gigabit poe switch

-provides 24 gigabit poe rj45 ports and 2* 1.25g sfp uplink port

-supports poe power up to 30w for each poe port ,320w for all poe ports

-supports poe ieee 802. 3at/af compliant powered device (pd)

-ieee 802.3x flow control for full duplex mode and backpressure for half duplex mode

-4kv professional lightning protection, no fear of lightning

-steel case, plug and play, no configuration required

  • 1
  • 2
  • 3
  • 4
1
2
3
4
ns1326gp

product parameters

product hardware specifications

product model

ns1326gp
standard protocol ieee802.3af/at series protocol
ieee802.3 ethernet media access control protocol
ieee802.3i 10base-t ethernet
ieee802.3u 100bast-tx fast ethernet
ieee802.3ab 1000base-t gigabit ethernet
ieee802.3x flow control
port

24*10/100/1000m poe rj45 port
2*1.25g sfp uplink port

poe standard

standard ieee802.3af/at protocol, the maximum power of a single port is 30w, and the maximum power of the machine is 320w

support overcurrent, overvoltage, short circuit protection

support high power pd soft start

support sequential boot

support certified non-standard pd power receiving

forwarding mode store and forward
basic functions compliant with ieee 802.3 ethernet and ieee802.3u fast ethernet protocol standards

compatible with ieee 802.3af/at compliant powered devices (pds)

compatible with certified non-standard powered devices (pd)

store and forward

mac automatic learning and aging

ieee802.3x full-duplex flow control and backpressure half-duplex flow control

forwarding rate 10/100/1000mbps
backplane bandwidth

56gbps

mac address table 8k
access method csma/cd
default working mode off: default working mode

on: port isolation

size 440mm(l)* 180mm(w)* 45mm (h)
power ac input 100v-250v 50/60hz
working environment

operating temperature: 0°c ~ 40°c

storage temperature: -40°c ~ 70°c

operating humidity: 10% ~ 90%, rh  non-condensing

storage humidity: 5% ~ 90%, rh non-condensing
