-provides 4 gigabit poe rj45 ports and 1 gigabit uplink rj45 port and 1 gigabit sfp uplink port
-supports poe power up to 30w for each poe port ,60w for all poe ports
-supports poe ieee 802. 3at/af compliant powered device (pd)
-ieee 802.3x flow control for full duplex mode and backpressure for half duplex mode
-4kv professional lightning protection, no fear of lightning
-supports 2k mac address table, mac address auto-learning & auto-aging
-steel case, plug and play, no configuration required
|
product model |
ns1306gp |
| standard protocol | ieee802.3af/at series protocol ieee802.3 ethernet media access control protocol ieee802.3i 10base-t ethernet ieee802.3u 100bast-tx fast ethernet ieee802.3ab 1000base-t gigabit ethernet ieee802.3x flow control |
| port |
4*10/100/1000m poe rj45 port |
| poe standard |
standard ieee802.3af/at protocol, the maximum power of a single port is 30w, and the maximum power of the machine is 60w support overcurrent, overvoltage, short circuit protection support high power pd soft start support sequential boot support certified non-standard pd power receiving |
| forwarding mode | store and forward |
| forwarding rate | 10/100/1000mbps |
| backplane bandwidth |
12gbps |
| mac address table | 2k |
| access method | csma/cd |
| default working mode | normal switch mode/vlan isolation |
| size | 125 mm(l)* 115mm(w)* 34mm (h) |
| power | ac input 220v 50/60hz |
| working environment |
operating temperature: 0°c ~ 40°c storage temperature: -40°c ~ 70°c operating humidity: 10% ~ 90%, rh non-condensing storage humidity: 5% ~ 90%, rh non-condensing |
