the machine power is 320w, and the sfp optical port can be connected to an optical fiber module that supports the ieee 802.3af/at standard protocol, and the maximum power of a single port is 30w.the poe port can automatically detect and identify the power receiving device that conforms to the ieee 802.3af/at standard, and supports network cable power supply;industrial grade steel shell, strong heat dissipation, ensures more stable operation of the switch.
product model |
ns1318gp-d |
standard protocol | ieee 802.3、ieee 802.3i、ieee 802.3u、ieee 802.3ab、ieee 802.3x、ieee 802.3af、ieee 802.3at |
port |
24*10/100/1000m poe rj45 port 2*10/100/1000m sfp uplink port |
poe standard |
standard ieee802.3af/at protocol, the maximum power of a single port is 30w, and the maximum power of the machine is 320w support overcurrent, overvoltage, short circuit protection support high power pd soft start support sequential boot support certified non-standard pd power receiving |
forwarding mode | store and forward |
basic functions | compliant with ieee 802.3 ethernet and ieee802.3u fast ethernet protocol standards
compatible with ieee 802.3af/at compliant powered devices (pds) compatible with certified non-standard powered devices (pd) store and forward mac automatic learning and aging ieee802.3x full-duplex flow control and backpressure half-duplex flow control |
forwarding rate | 10/100/1000mbps |
backplane bandwidth |
12.8gbps |
mac address table | 8k |
access method | csma/cd |
size | 440mm(l)* 180mm(w)* 43mm (h) |
power | ac input 100v-240v 50/60hz |
working environment |
operating temperature: 0°c ~ 40°c storage temperature: -40°c ~ 70°c operating humidity: 10% ~ 90%, rh non-condensing storage humidity: 5% ~ 90%, rh non-condensing |
