-provide 24 1000mbps rj45 ports 2 gigabit sfp fiber module expansion slots
-24 poe power supply ports, which can automatically detect and identify the powered devices that meet the ieee 802.3at/af standard, and supply power to them through the network cable
-3 toggle switches provide users with switching and superimposition in port isolation, dhcp server protection, and link aggregation
-simple and convenient to use, no configuration required, plug and play, flexibly expand the network of shopping malls, schools, and offices without the limitation of power line layout
|
product model |
ns1226pe |
| standard protocol | iieee802.3 10base-t ethernet standard ieee802.3u 100base-tx fast ethernet standard ieee802.3ab 1000base-t ethernet standard eee802.3z gigabit ethernet (optical) ieee802.3x full-duplex flow control and backpressure half-duplex flow control ieee802.3ad link aggregation ieee802.1q vlan |
| port |
24*10/100/1000m poe rj45 port 2*multiplexed gigabit sfp fiber module expansion slots |
| forwarding mode | store and forward |
| backplane bandwidth |
52gbps |
| mac address table | 8k |
| pwr、sys、poe max、link/act、1000m、port isolation、dhcp server protection、 link aggregation | |
| access method | csma/cd |
| size | 440*350*44mm（l*w*h） |
| power | 100-240v ac，50/60hz |
| working environment |
operating temperature: 0°c ~ 40°c storage temperature: -40°c ~ 70°c operating humidity: 10% ~ 90%, rh non-condensing storage humidity: 5% ~ 90%, rh non-condensing |
| network medium | 10base-t: cat3 and above unshielded/shielded twisted pair (≤100m)
100base-tx: cat5 and above unshielded/shielded twisted pair (≤100m) 1000base-tx: cate5 and above unshielded/shielded twisted pair (≤100m) |
