remote operation and maintenance via cloud network administrator, solve on-site problems remotely
port custom label, devices clear at a glance
120w power, gigabit ap/hd camera full load access
more features: port isolation, port restart, uplink and downlink speed control and so on
|
product model |
ns2310gpm |
| port | 8*10/100/1000m poe rj45 port 2*10/100/1000m uplink rj45 port |
| basic function |
ieee802.3 ethernet and ieee802.3u fast ethernet protocol standards compatible with electrical receiving devices (pd) that comply with ieee 802.3af/at standards compatibility with certified non-standard receiving equipment (pd) store-and-forward mac automatic learning and aging ieee802.3x full duplex flow control and backpressure half duplex flow control |
| backplane bandwidth | 20g |
| mac address table | 2k |
| power | ac input 100-250v，120w |
| standard protocol |
ieee 802.3 ethernet media access control protocol ieee 802.3i 10base-t ethernet ieee 802.3u 100base-tx fast ethernet ieee 802.3ab 1000base-t gigabit ethernet ieee 802.3af provides power to ethernet devices through ethernet data pair or devices ieee 802.3at implements high power supply for ethernet devices through ethernet data pair or devices ieee 802.3x flow control |
| data transmission |
ethernet 10mbps half duplex, 20mbps full duplex fast ethernet 100mbps half duplex, 200mbps full duplex gigabit ethernet 2000mbs full duplex |
| working environment |
operating temperature: 0°c ~ 40°c storage temperature: -40°c ~ 70°c operating humidity: 10% ~ 90%, rh non-condensing storage humidity: 5% ~ 90%, rh non-condensing |
| management mode | wechat managed |
|
cloud managed information viewing |
switch sn information, device model, firmware version, real-time ip address, real-time port power, port link status, link duplex |
| cloud managed
equipment operation |
port isolation, port restart, machine reset, firmware upgrade, real-time port power, port link status, uplink and downlink speed control |
| dimension | 190mm*140mm*43mm |
