intelligent wall penetration of wireless signal, effective coverage of wi-fi dead corners
built-in signal receiving amplifier, low noise/high sensitivity/no interference
4*5dbi high-gain antenna, wide coverage of signal through the wall
wechat remote management, more secure, more convenient
product model | power 4s |
standard protocol | ieee 802.11n ieee 802.11g ieee 802.11b ieee 802.3 ieee 802.3u |
interface overview |
four 10/100m adaptive lan ports, support automatic rollover(auto mdi/mdix) |
button | signal conditioning default button wifi on/off switch |
antenna | four 5dbi external 2.4g non-removable antennas |
led display | pwr: power status indicator signal: red-blue signal strength indicator wan:wan口link&act indicator lan:lan口link&act indicator |
dimensions | 380×273×60mm |
capacity storage | flash:4mb memory:32mb |
packing list | 300mbps wireless router power 4s power adapter user's manual |
operating environment | operating temperature: 0°c ~ 40°c storage temperature: -20°c ~ 70°c operating humidity: 10% ~ 90%, non-condensing storage humidity: 5% ~ 90%, non-condensing |
common functions | wi-fi settings signal conditioning wireless universal relay friends only network child mode indicator schedule off wi-fi schedule off port mapping peanut shell dynamic domain name one-click switch |
security |
malicious url blocking |
basic settin | system upgrade restart router reset dial log change management password modify router address my router information time settings developer mode |
others | wechat management plugin center emergency recovery |
fixed the bug of software network restart, optimized wifi performance, and increased compatibility with different browser vendors
upgrade description:
1. optimize wi-fi user experience
2. fix bugs that affect system stability
